Rievtech xLogic ELC Series User Manual page 376

Ambient temperature
Storage temperature
Certification
Mounting
Dimensions
Programming cable
Third party device(HMI)
<=> xLogic
Extensions
High speed input
HMI
RS485 port
Standard CPU Units
(PR-18 series)
Power supply:
Nominal voltage
Operating limits
Immunity from micro
power cuts
Max. Startup current
Max. absorbed power
Protection against polarity
inversions
The main frequency range
Input parameters:
Input No
Digital input
Analogue input
Input voltage
Input signal0
Input signal1
Input current
Input Response Time
-20 to + 55 ºC
–40 ºC to + 70 ºC
CE
On 35 mm standard mounting rail, 4 MW, or wall-mounting
W x H x D (72*90*61 mm)
PC cable, (RS232 or USB)
Yes (work as modbus master or slave)
Yes(Can connect up to 16 pcs PR-E extensions.)
No I7---IA(60kHz)
Yes
Option1:Built-in RS485 port
Option2:Can use PRO-RS485 cable to convert program port to RS485 port
Option3: use PR-RS485 extension module
PR-18AC-R PR-18DC-DA-R
AC110V-240V DC 12-24V
AC85 - 265 V DC 10.8-28.8V
--- Typ. 5 ms
--- Max. 0.25A
49mA (85V ac) ; 3.5 W (10.8V dc) ;
37mA (265V ac) 4 W (28.8V dc)
Yes Yes
47-63Hz ---
12 ( I1-IC ) 12 (I1-IC )
12 ( I1-IC ) 12 (I1-IC )
None 6 ( I1-I6)(0..10V DC)
AC0-240V DC 0-28.8V
AC0-40V；<0.03mA < 5V DC;<0.1mA(I1-I6),<1mA(I7-IC)
AC79-240V；
> 8 V DC;>0.3mA(I1-I6),>1.7mA(I7-IC)
>0.06mA
--- 0.4mA(I1-I6),2.3mA(I7-IC),@ 10.8V dc
0.5mA(I1-I6),2.6mA(I7-IC),@ 12.0 V dc
1.2mA(I1-I6),5.2mA(I7-IC),@ 24 V dc
1.5mA(I1-I6),6.3mA(I7-IC),@ 28.8 V dc
Delay time at 0 to 1： Delay time at 0 to 1 ：
120V AC ：Typ. 50 ms Typ. 1.5 ms (I1-I6),<1ms(I7-IC)；
240V AC ：Typ. 30 ms Delay time at 1 to 0 ：
Delay time at 1 to 0： Typ. 1.5 ms(I1-I6),<1ms(I7-IC)；
PR-18DC-DA-RT
376
