5.8.1.5 View

This instruction is to display the status bar, workspace and the Information window and so on. The pull
down menu is shown as the following:
※ Status bar: state bar displaying instruction
※ Workspace: workspace displaying instruction
※ Info Window: Info window displaying instruction
※ Zoom: window proportion displaying instruction. There are four different sizes of the windows for the
user to select.

5.8.1.6 Help

※ Content Index: Help index and detailed contents
※ About xLogicsoft
※ Version information

5.8.2 Toolbar

The icons of the standard toolbar provide quick access to commands that are also available on the menu.
Standard
Toolbar
New
Open
Fig. 10.5 View Menu
Zoom In
Zoom Out
228
