Programming cable
Third party device(HMI)
<=> xLogic
Extensions
High speed input
HMI
RS485 port
Standard CPU Units
(PR-18 series)
Power supply:
Nominal voltage
Operating limits
Immunity from micro
power cuts
Max. Startup current
Max. absorbed power
Protection against polarity
inversions
The main frequency range
Input parameters:
Input No
Digital input
Analogue input
Input voltage
Input signal0
Input signal1
Input current
Input Response Time
Maximum counting
frequency
Sensor type
Isolation between power
supply and inputs
PC cable, (RS232 or USB)
Yes (work as modbus master or slave)
No
No I5---I8(60kHz)
Yes
Option1:Can use PRO-RS485 cable to convert program port to RS485 port
PR-14AC-R PR-14DC-DA-R
AC110V-240V DC 12-24V
AC85 - 265 V DC 10.8-28.8V
--- Typ. 5 ms
--- Max. 0.25A
49mA (85V ac) ; 3.5 W (10.8V dc) ;
37mA (265V ac) 4 W (28.8V dc)
Yes Yes
47-63Hz ---
10 ( I1-IA ) 10 (I1-IA )
10 ( I1-IA ) 10 (I1-IA )
None 6 ( I1-I6)(0..10V DC)
AC0-240V DC 0-28.8V
AC0-40V；<0.03mA < 5V DC;<0.1mA(I1-I6),<1mA(I7-IC)
AC79-240V；
> 8 V DC;>0.3mA(I1-I6),>1.7mA(I7-IC)
>0.06mA
--- 0.4mA(I1-I6),2.3mA(I7-IC),@ 10.8V dc
0.5mA(I1-I6),2.6mA(I7-IC),@ 12.0 V dc
1.2mA(I1-I6),5.2mA(I7-IC),@ 24 V dc
1.5mA(I1-I6),6.3mA(I7-IC),@ 28.8 V dc
Delay time at 0 to 1： Delay time at 0 to 1 ：
120V AC ：Typ. 50 ms Typ. 1.5 ms (I1-I6),<1ms(I7-IC)；
240V AC ：Typ. 30 ms Delay time at 1 to 0 ：
Delay time at 1 to 0： Typ. 1.5 ms(I1-I6),<1ms(I7-IC)；
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Typ. 4Hz Typ.：4 HZ
Contact or 3-wire PNP Contact or 3-wire PNP
None Resistive
