Rievtech xLogic ELC Series User Manual page 384

Weight
Short-circuit protection
Cycle time
Connection cables
Ambient temperature
Storage temperature
Certification
Mounting
Dimensions
RS485 communication module
(PR-RS485)
Power supply:
Nominal voltage
Operating limits
Immunity from micro power cuts
Max. Startup current
Max. absorbed power
Protection against polarity inversions
Input parameters:
None
Output parameters:
None
Other parameters:
Weight
Short-circuit protection
Connection cables
Ambient temperature
Storage temperature
Certification
Mounting
Dimensions
Ethernet CPU Units
(ELC-12-N series)
Power supply:
Nominal voltage
Operating limits
Immunity from micro
power cuts
Max. Startup current
Max. absorbed power
Approx.400g
External fuse required
typ. 0.6ms ➞ 8.0ms
2 x 1.5 mm² or 1 x 2.5 mm²
-20 to + 55 ºC
–40 ºC to + 70 ºC
CE
On 35 mm standard mounting rail, 4 MW, or wall-mounting
W x H x D (72*90*58 mm)
PR-RS485
DC 12-24V
DC 10.8-28.8V
Typ. 5 ms
Max. 0.1A
1.5 W (10.8V dc) ; 1.8W W (28.8V dc)
Yes
Approx.400g
External fuse required
2 x 1.5 mm² or 1 x 2.5 mm²
-20 to + 55 ºC
–40 ºC to + 70 ºC
CE
On 35 mm standard mounting rail, 4 MW, or wall-mounting
W x H x D (72*90*58 mm)
ELC-12AC-R-N
AC110V-240V
AC85 - 265 V
---
---
48.5mA (85V ac) ;
ELC-12DC-DA-R-N
DC 12-24V
DC 10.8-28.8V
Typ. 5 ms
Max. 0.25A
3.5 W (10.8V dc) ;
384
