General Specifications - Danfoss VLT AutomationDrive FC 300 Design Manual

Selection

4.3 General Specifications

Line Power Supply
Supply terminals (6-Pulse)
Supply terminals (12-Pulse)
Supply voltage
Supply voltage
4 4
AC line voltage low/line drop-out:
During low AC line voltage or a line drop-out, the adjustable frequency drive continues until the intermediate circuit voltage
drops below the minimum stop level, which corresponds typically to 15% below the adjustable frequency drive's lowest rated
supply voltage. Power-up and full torque cannot be expected at AC line voltage lower than 10% below the adjustable frequency
drive's lowest rated supply voltage.
Supply frequency
Max. temporary imbalance between line phases
True power factor (λ)
Displacement Power Factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≥ 90 kW
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600/690
V maximum.
Motor Output (U, V, W)
Output voltage
Output frequency (125–1350 hp [90–1000 kW])
Output frequency in flux mode (FC 302 only)
Switching on output
Ramp times
1)
Voltage and power dependent.
Torque Characteristics
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Starting torque (Variable torque)
Torque rise time in VVC
Torque rise time in FLUX (for 5 kHz fsw)
1) Percentage relates to the nominal torque.
2) The torque response time depends on application and load but as a general rule, the torque step from 0 to reference is 4–5 x
torque rise time.
Cable Lengths and Cross-sections for Control Cables
Max. motor cable length, shielded
Max. motor cable length, non-shielded
Maximum cross-section to control terminals, flexible/rigid wire without cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves with collar
Minimum cross-section to control terminals
1)
For power cables, see chapter 4.1 Electrical Data, 380–500 V.
78
Design Guide
plus
(independent of fsw)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Overvoltage category III/pollution degree 2
1)
L1, L2, L3
L1-1, L2-1, L3-1, L1-2, L2-2, L3-2
380–500 V ±10%
FC 302: 525–690 V ±10%
50/60 Hz ±5%
3.0% of rated supply voltage
≥0.9 nominal at rated load
near unity (>0.98)
Maximum 1 time/2 min.
0–100% of supply voltage
1)
0–590 Hz
0–300 Hz
Unlimited
0.01–3600 s
maximum 160% for 60 s
maximum 180% up to 0.5 s
maximum 160% for 60 s
maximum 110% for 60 s
10 ms
1 ms
500 ft [150 m]
1,000 ft [300 m]
1.5 mm 2 /16 AWG
1 mm 2 /18 AWG
2
0.5 mm /20 AWG
2
0.25 mm /24 AWG
MG34S222
