Mechanical Installation
6
6
Figure 6.58 Terminal Locations, D8h with Contactor and Disconnect Options
1
TB6 Terminal block for contactor
2
Line Power Terminals
3
Brake Terminals
4
Motor Terminals
5
Ground Terminals
Table 6.31 Legend to Figure 6.58
144
C-C
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Design Guide
1
2
567
[
22.3
3
4
5
C
]
0
C
[ ]
0
S
R
T
MG34S222
