Mechanical Installation
Terminal Locations - Frame Size E2
Take the following position of the terminals into consideration when designing the cable access.
6 6
186[7.3]
17[0.7]
Figure 6.64 IP00 Enclosure Power Connection Positions
150
Design Guide
FASTENER TORQUE M8 9.6 Nm (7 FT-LB) FASTENER TORQUE M8 9.6 Nm (7 FT-LB)
R/L1 91 S/L2 92 T/L3 93
9 U/T1 96 V/T2 97
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
W/T3 98
0[0.0]
MG34S222
