Electrical Installation
FC 302 [kW]
450
500
560
630
710
800
Table 7.34 380–480/500 V, Frame Size F, Inverter Module DC Link Fuses
VLT© Model
N55k T7
N75k T7
N90k T7
N110 T7
N132 T7
7 7
N160 T7
N200 T7
N250 T7
N315 T7
Table 7.35 Fuse Options for 525–690 V, Frame Size D
NOTICE!
For UL compliance, the Bussmann 170M series fuses must be used for units supplied without a contactor-only option.
For units supplied with a contactor-only option, see Table 7.28 for SCCR ratings and UL fuse criteria.
FC 302 [kW]
355
400
500
560
Table 7.36 525–690 V, Frame Size E, Line Fuse Options for UL Compliance
FC 302 [kW]
630
710
800
900
1000
1200
Table 7.37 525–690 V, Frame Size F, Line Fuse Options for UL Compliance
212
Design Guide
Drive internal Bussmann PN
170M8611
170M8611
170M6467
170M6467
170M8611
170M6467
Bussmann PN Siba PN
170M2616 20 610 31.160
170M2619 20 610 31.315
170M2619 20 610 31.315
170M2619 20 610 31.315
170M2619 20 610 31.315
170M4015 20 620 31.550
170M4015 20 620 31.550
170M4015 20 620 31.550
170M4015 20 620 31.550
Recommended drive Rating
external fuse
Bussmann PN
170M4017 700 A, 700 V
170M4017 700 A, 700 V
170M6013 900 A, 700 V
170M6013 900 A, 700 V
Recommended drive
external fuse
Bussmann PN
170M7081
170M7081
170M7081
170M7081
170M7082
170M7083
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Rating
1100 A, 1000 V
1100 A, 1000 V
1400 A, 700 V
1400 A, 700 V
1100 A, 1000 V
1400 A, 700 V
Ferraz-Shawmut European PN
6.9URD30D08A0160
6.9URD31D08A0315
6.9URD31D08A0315
6.9URD31D08A0315
6.9URD31D08A0315
6.9URD32D08A0550
6.9URD32D08A0550
6.9URD32D08A0550
6.9URD32D08A0550
Drive internal Alternate external
option
Bussmann PN
170M4017 20 610 32.700
170M4017 20 610 32.700
170M6013 22 610 32.900
170M6013 22 610 32.900
Rating Drive internal option
Bussmann PN
1600 A, 700 V 170M7082
1600 A, 700 V 170M7082
1600 A, 700 V 170M7082
1600 A, 700 V 170M7082
2000 A, 700 V 170M7082
2500 A, 700 V 170M7083
Alternate Siba PN
20 781 32.1000
20 781 32.1000
20 681 32.1400
20 681 32.1400
20 781 32.1000
20 681 32.1400
Ferraz-Shawmut North American PN
A070URD30KI0160
A070URD31KI0315
A070URD31KI0315
A070URD31KI0315
A070URD31KI0315
A070URD32KI0550
A070URD32KI0550
A070URD32KI0550
A070URD32KI0550
Alternate external
Siba PN Ferraz-Shawmut PN
6.9URD31D08A0700
6.9URD31D08A0700
6.9URD33D08A0900
6.9URD33D08A0900
Alternate Siba PN
20 695 32.1600
20 695 32.1600
20 695 32.1600
20 695 32.1600
20 695 32.2000
20 695 32.2500
