Drive Configurator - Danfoss VLT AutomationDrive FC 300 Design Manual

How to Order
Product groups
Adjustable frequency drive series
Generation code
Power rating
Phases
AC Line Voltage
Enclosure
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter/Low Harmonic Drive/12-
pulse
Brake
Display (LCP)
Coating PCB
Line power option
Adaptation A
Adaptation B
Software release
Software language
A options
B options
C0 options, MCO
C1 options
C option software
D options
Table 5.2 Type Code Example for Ordering an Adjustable
Frequency Drive
Not all choices/options are available for each FC 302
variant. To verify if the appropriate version is available,
consult the drive configurator on the Internet.
MG34S222
Design Guide
1-3
4-6
7
8-10
11
12
13-15
16-23
16-17
18
19
20
21
22
23
24-27
28
29-30
31-32
33-34
35
36-37
38-39
Danfoss A/S © Rev. 2014-02-10 All rights reserved.

5.1.2 Drive Configurator

It is possible to design an FC 300 adjustable frequency
drive according to the application requirements by using
the ordering number system shown in Table 5.1 and
Table 5.2.
For the FC 300 series, order standard adjustable frequency
drives and adjustable frequency drives with integral
options by sending a type code string describing the
product to the local Danfoss sales office, for example:
FC-302N132T5E20H4BGCXXXSXXXXA0BXCXXXXD0
The meaning of the characters in the string are defined in
Table 5.3. Additional detail is provided for each adjustable
frequency drive in the can be located in the pages
containing the ordering numbers in this chapter. In the
example above, a Profibus DP V1 and a 24 V backup
option is included in the adjustable frequency drive.
Use the drive configurator to configure the appropriate
drive for the right application. The drive configurator
automatically generates an 8-digit sales number to be
delivered to the local sales office.
It is also possible to establish a project list with several
products and send it to a Danfoss sales representative.
The drive configurator can be found on the global Internet
site: www.danfoss.com/drives.
Adjustable frequency drives are delivered automatically
with a language package relevant to the region from
which they are ordered. Four regional language packages
cover the following languages:
Language Package 1
English, German, French, Danish, Dutch, Spanish, Swedish,
Italian, and Finnish.
Language Package 2
English, German, Chinese, Korean, Japanese, Thai,
Traditional Chinese, and Bahasa Indonesian.
Language Package 3
English, German, Slovenian, Bulgarian, Serbian, Romanian,
Hungarian, Czech, and Russian.
