Mechanical Installation
5
A-A
4
Figure 6.57 Terminal Locations, D8h with Contactor Option
1 TB6 Terminal block for contactor
2 Motor Terminals
3 Ground Terminals
4 Brake Terminals
5 Line Power Terminals
Table 6.30 Legend to Figure 6.57
MG34S222
Design Guide
A
B
898
[ 35.3 ]
3
418
[ 16.5 ]
378
[ 14.9 ]
0
0 [ ]
B
A
V
U
T
W
R
S
