Danfoss VLT AutomationDrive FC 300 Design Manual page 96

How to Order
Description
Line power
option
5 5
Power
Terminals &
Motor Starters
Auxiliary 24 V
Supply &
External
Temperature
Monitoring
Software
release
Software
language
* Requires MCB 112 and MCB 113
Table 5.5 Ordering Type Code for F-frame Adjustable
Frequency Drives
94
Design Guide
Pos Possible choice
21 X: No line power option
3: Line power disconnect and fuse
5: Line power disconnect, fuse and load
sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
E: Line power disconnect, contactor &
fuses
F: Line power circuit breaker, contactor
& fuses
G: Line power disconnect, contactor,
load sharing terminals & fuses
H: Line power circuit breaker, contactor,
load sharing terminals & fuses
J: Line power circuit breaker & fuses
K: Line power circuit breaker, load
sharing terminals & fuses
22 X: No option
E 30 A, fuse-protected power terminals
F: 30 A, fuse-protected power terminals
& 2.5-4 A manual motor starter
G: 30 A, fuse-protected power terminals
& 4-6.3 A manual motor starter
H: 30 A, fuse-protected power terminals
& 6.3-10 A manual motor starter
J: 30 A, fuse-protected power terminals
& 10-16 A manual motor starter
K: Two 2.5-4 A manual motor starters
L: Two 4-6.3 A manual motor starters
M: Two 6.3-10 A manual motor starters
N: Two 10-16 A manual motor starters
23 X: No option
H: 5 A, 24 V power supply (customer
use)
J: External temperature monitoring
G: 5 A, 24 V power supply (customer
use) & external temperature monitoring
24-27 Current software
24-28 S023: 316 Stainless Steel Backchannel -
high power drives only
28
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Description
A options
B options
2)
C0/ E0 options 33-
C1 options/
A/B in C
Option
Adaptor
C option
software/
E1 options
D options
Table 5.6 Ordering Options for All Frame Sizes
Pos Possible choice
29- AX: No A option
30 A0: MCA 101 Profibus DP V1 (standard)
A4: MCA 104 DeviceNet (standard)
A6: CANOpen MCA 105 (standard)
AN: MCA 121 Ethernet IP
AL: MCA-120 ProfiNet
AQ: MCA-122 Modbus TCP
AT: MCA 113 Profibus Drive VLT3000
AU: MCA-114 Profibus Drive VLT5000
31- BX: No option
32 BK: MCB 101 General purpose I/O
option
BR: MCB 102 Encoder option
BU: MCB 103 Resolver option
BP: MCB 105 Relay option
BZ: MCB 108 Safety PLC Interface
B2: MCB 112 PTC Thermistor Card
B4: MCB-114 VLT Sensor Input
CX: No option
34 C4: MCO 305, Programmable Motion
Controller
BK: MCB 101 General purpose I/O in E0
BZ: MCB 108 Safety PLC Interface in E0
35 X: No option
R: MCB 113 Ext. Relay Card
Z: MCA 140 Modbus RTU OEM option
E: MCF 106 A/B in C Option Adaptor
36- XX: Standard controller
37 10: MCO 350 Synchronizing control
11: MCO 351 Positioning control
12: MCO 352 Center winder
AN: MCA 121 Ethernet IP in E1
BK: MCB 101General purpose I/O in E1
BZ: MCB 108 Safety PLC Interface in E1
38- DX: No option
39 D0: MCB 107 Ext. 24 V DC backup
MG34S222
