Electrical Installation
Figure 7.16 Terminal Locations, D8h with Circuit Breaker Option
1
Line Power Terminals
2
Brake Terminals
Table 7.14 Legend to Figure 7.16
MG34S222
Design Guide
1
605
[
23.8
2
3
4
3
Motor Terminals
4
Ground Terminals
