Product Introduction
Frame size
3 3
Enclosure IP
protection
NEMA
High overload
rated power -160%
overload torque
Table 3.1 Product Overview, 6-Pulse Adjustable Frequency Drives
Frame size
Enclosure
protection
High overload rated
power -160%
overload torque
Table 3.2 Product Overview, 12-Pulse Adjustable Frequency Drives
20
E1
21/54
Type 1/Type 12
350–550 hp [250–400 kW]
at 400 V
(380–500 V)
475–750 hp [355–560 kW]
at 690 V
(525–690 V)
F8 F9
F9 F8
IP 21/54 21/54
NEMA Type 1/Type 12 Type 1/Type 12
350–550 hp 350–550 hp
[250–400 kW] [250–400 kW]
(380–500 V) (380–500 V)
475–750 hp 475–750 hp
[355–560 kW] [355–560 kW]
(525–690 V) (525–690 V)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Design Guide
E2 F1/F3
00 21/54
Chassis Type 1/Type 12
350–550 hp 600–850 hp [450–630 kW]
[250–400 kW] at 400 V at 400 V
(380–500 V) (380–500 V)
475–750 hp 850–1075 hp [630–800 kW]
[355–560 kW] at 690 V at 690 V
(525–690 V) (525–690 V)
F10 F11
F11
F10
21/54 21/54
Type 1/Type 12 Type 1/Type 12
600–850 hp 600–850 hp
[450–630 kW] [450–630 kW]
(380–500 V) (380–500 V)
850–1075 hp 850–1075 hp
[630–800 kW] [630–800 kW]
(525–690 V) (525–690 V)
F2/ F4
F4 F2
F3 F1
21/54
Type 1/Type 12
950–1075 hp [710–800 kW] at
400 V
(380–500 V)
1200–1350 hp [900–1000 kW]
at 690 V
(525–690 V)
F12
F13
F12
21/54
Type 1/Type 12
950–1075 hp
[710–800 kW]
(380–500 V)
1200–1600 hp
[900–1200 kW]
(525–690 V)
F13
21/54
Type 1/Type 12
950–1075 hp
[710–800 kW]
(380–500 V)
1200–1600 hp
[900–1200 kW]
(525–690 V)
