Mechanical Installation
Frame size
IP
NEMA
Shipping
dimensions (in
[mm])
Drive
6 6
dimensions (in
[mm])
Max weight (lbs [kg])
Table 6.19 Mechanical Dimensions, Frame Size D1h-D4h
Frame size
IP
NEMA
Shipping dimensions
(in [mm])
Drive dimensions (in
[mm])
Max weight (lbs [kg])
Table 6.20 Mechanical Dimensions, Frame Size D5h-D8h
124
Design Guide
D1h D2h
125–175 hp 250–350 hp
[90–132 kW] [160–250 kW]
(380–500 V) (380–500 V)
125–175 hp 250–450 hp
[90–132 kW] [160–315 kW]
(525–690 V) (525–690 V)
21/54 21/54
Type 1/12 Type 1/12
Height 23.11 [587] 23.11 [587]
Width 39.25 [997] 46.06 [1170]
Depth 18.11 [460] 21.06 [535]
Height 35.47 [901] 41.73 [1060]
Width 12.80 [325] 16.54 [420]
Depth 14.88 [378] 14.88 [378]
216.05 [98] 361.56 [164]
D5h
125–175 hp
[90–132 kW]
(380–500 V)
125–175 hp
[90–132 kW]
(525–690 V)
21/54
Type 1/12
Height 25.98 [660]
Width 71.65 [1820]
Depth 20.08 [510]
Height 52.13 [1324]
Width 12.80 [325]
Depth 15.0 [381]
255.74 [116]
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
D3h D4h
125–175 hp 250–350 hp
[90–132 kW] [160–250 kW]
(380–500 V) (380–500 V)
50–175 hp 250–450 hp
[37–132 kW] [160–315 kW]
(525–690 V) (525–690 V)
20 20
Chassis Chassis
23.11 [587] 23.11 [587]
39.25 [997] 46.06 [1170]
18.11 [460] 21.06 [535]
35.79 [909] 44.17 [1122]
9.84 [250] 13.78 [350]
14.76 [375] 14.76 [375]
216.05 [98] 361.56 [164]
D6h D7h
125–175 hp
[90–132 kW] 250–350 hp [160–250 kW]
(380–500 V) (380–500 V)
125–175 hp 250–450 hp [160–315 kW]
[90–132 kW] (525–690 V)
(525–690 V)
21/54 21/54
Type 1/12 Type 1/12
25.98 [660] 25.98 [660]
71.65 [1820] 97.24 [2470]
20.08 [510] 23.23 [590]
65.47 [1663] 77.87 [1978]
12.80 [325] 16.54 [420]
15.0 [381] 15.20 [386]
284.40 [129] 440.92 [200]
D3h D4h
With Regeneration or Load
Share Terminals
20 20
Chassis Chassis
23.11 [587] 23.11 [587]
48.43 [1230] 56.30 [1430]
18.11 [460] 21.06 [535]
39.53 [1004] 49.93 [1268]
9.84 [250] 13.78 [350]
14.76 [375] 14.76 [375]
238.10 [108] 394.63 [179]
D8h
250–350 hp
[160–250 kW]
(380–500 V)
250–450 hp
[160–315 kW]
(525–690 V)
21/54
Type 1/12
25.98 [660]
97.24 [2470]
23.23 [590]
89.92 [2284]
16.54 [420]
15.98 [406]
496.04 [225]
