Mechanical Installation
F
E
Figure 6.63 IP21 (NEMA type 1) and IP54 (NEMA type 12) Enclosure Power Connection Position of Disconnect Switch
Frame size Unit type
IP54/IP21 UL and NEMA1/NEMA12
350/450 hp [250/315 kW] (400 V) and
475/600–650/850 hp
[355/450–500/630 KW]
E1
(690 V)
450/475–550/600 hp
[315/355-400/450 kW]
(400 V)
Table 6.33 Legend to Figure 6.63
MG34S222
Design Guide
0 [ 0.0 ]
28 [ 1.1
167 [ 6.6
195 [ 7.7
Dimension for disconnect terminal, mm (in)
A B
381 (15.0) 253 (9.9)
371 (14.6) 251 (9.9)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
]
]
]
C D
342 (13.5) 431 (17.0) 562 (22.1)
341 (13.4) 431 (17.0) 416 (16.4)
6
E F
N/A
455 (17.9)
