How to Order
Description Pos Possible choice
Adaptation 22 X: Standard cable entries
Adaptation 23 X: No adaptation
Software 24-27 Current software
release
Software 28
language
Table 5.4 Ordering Type Code for E-frame Adjustable
Frequency Drives
1)
Available for 380–480/500 V only.
2)
Consult the factory for applications requiring maritime certification.
Description Pos Possible choice
Product group 1-6 FC 302
Power rating 8-10 450–1200 kW
Phases 11 Three phases (T)
AC line 11-12 T 5: 380–500 V AC
voltage T 7: 525–690 V AC
Enclosure 13-15 C21: IP21/NEMA Type 1 with stainless
steel back channel
C54: IP54/Type 12 Stainless steel
backchannel
E21: IP 21/ NEMA Type 1
E54: IP 54/ NEMA Type 12
L2X: IP21/NEMA 1 with cabinet light &
IEC 230 V power outlet
L5X: IP54/NEMA 12 with cabinet light &
IEC 230 V power outlet
L2A: IP21/NEMA 1 with cabinet light &
NAM 115 V power outlet
L5A: IP54/NEMA 12 with cabinet light &
NAM 115 V power outlet
H21: IP21 with space heater and
thermostat
H54: IP54 with space heater and
thermostat
R2X: IP21/NEMA1 with space heater,
thermostat, light & IEC 230 V outlet
R5X: IP54/NEMA12 with space heater,
thermostat, light & IEC 230 V outlet
R2A: IP21/NEMA1 with space heater,
thermostat, light, & NAM 115 V outlet
R5A: IP54/NEMA12 with space heater,
thermostat, light, & NAM 115 V outlet
MG34S222
Design Guide
Description
RFI filter
Brake
Display
Coating PCB
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Pos Possible choice
16-17 H2: RFI filter, class A2 (standard)
H4: RFI filter, class A1
HE: RCD with Class A2 RFI filter
HF: RCD with class A1 RFI filter
HG: IRM with Class A2 RFI filter
HH: IRM with class A1 RFI filter
HJ: NAMUR terminals and class A2 RFI
filter
HK: NAMUR terminals with class A1 RFI
filter
HL: RCD with NAMUR terminals and
class A2 RFI filter
HM: RCD with NAMUR terminals and
class A1 RFI filter
HN: IRM with NAMUR terminals and
class A2 RFI filter
HP: IRM with NAMUR terminals and
class A1 RFI filter
N2: Low Harmonic Drive with RFI filter,
class A2
N4: Low Harmonic Drive with RFI filter,
class A1
B2: 12-pulse drive with RFI filter, class
A2
B4: 12-pulse drive with RFI filter, class
A1
BE: 12-pulse + RCD for TN/TT line
power + Class A2 RFI
BF: 12-pulse + RCD for TN/TT line
power + Class A1 RFI
BG: 12-pulse + IRM for IT line power +
Class A2 RFI
BH: 12-pulse + IRM for IT line power +
Class A1 RFI
BM: 12-pulse + RCD for TN/TT line
power + NAMUR Terminals + Class A1
RFI*
18 B: Brake IGBT mounted
X: No brake IGBT
C: Safe Stop with Pilz Relay
D: Safe Stop with Pilz Safety Relay &
Brake IGBT
R: Regeneration terminals
M: IEC Emergency stop pushbutton
(with Pilz safety relay)
N: IEC Emergency stop pushbutton with
brake IGBT and brake terminals
P: IEC Emergency stop pushbutton with
regeneration terminals
19 G: Graphical Local Control Panel LCP
20 C: Coated PCB
