Electrical Installation
Terminal Locations - Frame Size E2
FASTENER TORQUE M8 9.6 Nm (7 FT-LB)
R/L1 91
186[7.3]
17[0.7]
Figure 7.20 IP00 Enclosure Power Connection Positions
MG34S222
Design Guide
FASTENER TORQUE M8 9.6 Nm (7 FT-LB)
S/L2 92
T/L3 93
9
U/T1 96
V/T2 97
W/T3 98
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
0[0.0]
7
7
197
