7.2.5 Power/Semiconductor Fuse Options

Power
size
Bussman Littelfuse PN Littelfuse
PN
N90K 170M2619 LA50QS300-4 L50S-300
N110 170M2620 LA50QS350-4 L50S-350
N132 170M2621 LA50QS400-4 L50S-400
N160 170M4015 LA50QS500-4 L50S-500
N200 170M4016 LA50QS600-4 L50S-600
N250 170M4017 LA50QS800-4 L50S-800
Table 7.31 380–480/500 V, Frame Size D, Line Fuse Options
NOTICE!
For UL compliance, the Bussmann 170M series fuses must be used for units supplied without a contactor-only option.
For units supplied with a contactor-only option, see Table 7.28 for SCCR ratings and UL fuse criteria.
FC 302 [kW] Recommended drive
external fuse
Bussmann PN
250 170M4017
315 170M6013
355 170M6013
400 170M6013
Table 7.32 380–480/500 V, Frame Size E, Line Fuse Options for UL Compliance
FC 302 [kW] Recommended drive
external fuse
Bussmann PN
450
500
560
630
710
800
Table 7.33 380–480/500 V, Frame Size F, Line Fuse Options for UL Compliance
MG34S222
Design Guide
Bussmann Siba PN
PN PN
FWH-300A 20 189
20.315
FWH-350A 20 189
20.350
FWH-400A 20 189
20.400
FWH-500A 20 610
31.550
FWH-600A 20 610
31.630
FWH-800A 20 610
31.800
Rating
700 A, 700 V
900 A, 700 V
900 A, 700 V
900 A, 700 V
Rating
170M7081 1600 A, 700 V
170M7081 1600 A, 700 V
170M7082 2000 A, 700 V
170M7082 2000 A, 700 V
170M7083 2500 A, 700 V
170M7083 2500 A, 700 V
