Mechanical Installation
A-A
Figure 6.53 Terminal Locations, D6h with Contactor and Disconnect Options
1 Brake Terminals
2 TB6 Terminal block for contactor
3 Motor Terminals
4 Ground Terminals
5 Line Power Terminals
Table 6.26 Legend to Figure 6.53
MG34S222
Design Guide
1
5
225
[ 8.9
4
0
[ 0.0
