Mechanical Installation
Terminal Locations - Options Cabinet with Circuit Breaker/Molded Case Switch (F3 and F4)
Figure 6.73 Terminal Locations - Options Cabinet with Circuit Breaker/Molded Case Switch (Left, Front and Right Side View).
Connector Plate is 1.65 in [42 mm] below .0 Level.
1 Ground bar
Table 6.39 Legend to Figure 6.73
Power size
600 hp [450 kW] (480 V), 850–950 hp
[630–710 kW] (690 V)
650–1075 hp [500–800 kW] (480 V),
1075–1350 hp [800–1000 kW] (690 V)
Table 6.40 Dimension for Terminal
MG34S222
Design Guide
134.6 [5.30]
0.0 [0.00]
2
34.9
46.3
