Danfoss VLT AutomationDrive FC 300 Design Manual page 154

Mechanical Installation
6 6
F
E
Figure 6.66 IP00 Enclosure Power Connections, Position of Disconnect Switch
Frame size
E2
450/475–550/600 hp [315/355-400/450 kW]
Table 6.34 Disconnect Terminal Locations - Frame Size E2
152
Unit type
IP00/CHASSIS
350/450 hp [250/315 kW] (400 V) and
475/600–650/850 hp
[355/450–500/630 KW]
(690 V)
(400 V)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
Design Guide
0
[ 0.0 ]
Dimension for disconnect terminal, mm (in)
A B
381 (15.0) 245 (9.6)
383 (15.1) 244 (9.6)
C D
334 (13.1) 423 (16.7) 256 (10.1)
334 (13.1) 424 (16.7) 109 (4.3)
E F
N/A
149 (5.8)
MG34S222
