Mechanical Installation
2280
(89.7)
2205
(86.8)
1497
(58.9)
Figure 6.26 Mechanical Dimensions, F4
1 Minimum clearance from ceiling
Table 6.18 Legend to Figure 6.26
MG34S222
Design Guide
2401
(94.5)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
1
225.0
Ø29
(8.85)
(1.1)
604
(23.8)
6
6
123
