Product Introduction

3 Product Introduction

3.1 Product Overview

Frame size D1h
Enclosure IP 21/54
protection
NEMA Type 1/Type 12
High overload 125–175 hp [90-132 kW] at
rated power -160% 400 V
overload torque (380–500 V)
75–175 hp [55–132 kW] at
690 V
(525–690 V)
Frame size D5h
Enclosure IP 21/54
protection
NEMA Type 1/Type 12
High overload 125–175 hp [90-132 kW] at
rated power -160% 400 V
overload torque (380–500 V)
75–175 hp [55–132 kW] at
690 V
(525–690 V)
MG34S222
Design Guide
D2h D3h
21/54 20
Type 1/Type 12 Chassis
225–350 hp 125–175 hp [90-132 kW] at
[160–250 kW] at 400 V 400 V
(380–500 V) (380–500 V)
225–425 hp 75–175 hp [55–132 kW] at
[160–315 kW] at 690 V 690 V
(525–690 V) (525–690 V)
D6h D7h
21/54 21/54
Type 1/Type 12 Type 1/Type 12
125–175 hp [90-132 kW] 225–350 hp [160–250 kW]
at 400 V at 400 V
(380–500 V) (380–500 V)
75–175 hp [55–132 kW] 225–425 hp [160–315 kW]
at 690 V at 690 V
(525–690 V) (525–690 V)
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
D4h
20
Chassis
225–350 hp [160–250 kW] at
400 V
(380–500 V)
225–425 hp [160–315 kW] at
690 V
(525–690 V)
D8h
21/54
Type 1/Type 12
225–350 hp [160–250 kW] at
400 V
(380–500 V)
225–425 hp [160–315 kW] at
690 V
(525–690 V)
