Danfoss VLT AutomationDrive FC 300 Design Manual page 115

Mechanical Installation
96
[3.8]
211
[8.3]
879
[34.6]
623
[24.5]
Figure 6.9 Mechanical Dimensions, D2h
1 Ceiling
2 Air space outlet minimum 225 mm [8.9 in]
3 Air space inlet minimum 225 mm [8.9 in]
4 Floor
Table 6.3 Legend to Figure 6.9
NOTICE!
If using a kit to direct the airflow from the heatsink to
the outside vent on the back of the adjustable frequency
drive, the required ceiling clearance is 4 in [100 mm].
1
33
[1.3]
20
[0.8]
25
[1.0]
11
[0.4]
Figure 6.10 Detail Dimensions, D2h
1 Top mounting hole detail
2 Bottom mounting slot detail
Table 6.4 Legend to Figure 6.10
MG34S222
Design Guide
379
[14.9]
142
[5.6]
18
[0.7]
20
[0.8]
148
1050
[5.8]
[41.3]
718
[28.3]
2
75
[2.9]
11
[0.4]
12
[0.5]
24
9
[0.9]
[0.3]
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
420
[16.5]
346
[13.6]
280
[11.0]
130
[5.1]
107
[4.2]
213
[8.4]
1107 320
[12.6]
[43.6]
1051
[41.4]
857
[33.7]
271
[10.7]
1
2
6
4
113
6
