Positioner - Siemens SIMOCODE pro Function Manual

3.2.12

Positioner

Table 3- 15 Assignment of cyclic receive / send data, positioner
Cyclic receive data
Bit 0.0
Bit 0.1
Bit 0.2
Bit 0.3
Bit 0.4
Bit 0.5
Bit 0.6
Bit 0.7
Bit 1.0
Bit 1.1
Bit 1.2
Bit 1.3
Bit 1.4
Bit 1.5
Bit 1.6
Bit 1.7
Byte 2/3 *) (analog value)
Cycl. send data
Bit 0.0
Bit 0.1
Bit 0.2
Bit 0.3
Bit 0.4
Bit 0.5
Bit 0.6
Bit 0.7
Bit 1.0
Bit 1.1
Bit 1.2
Bit 1.3
Bit 1.4
Bit 1.5
Bit 1.6
Bit 1.7
Byte 2/3 (analog value)
Byte 4/5 *) (analog value)
Byte 6/7 *) (analog value)
Byte 8/9 *) (analog value)
*) for SIMOCODE pro V / pro S, basic type 1 only
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.2 Assignment of cyclic receive and send data for predefined control functions
Device parameters → Motor control → Control stations → PLC/PCS [DP] → Close
Device parameters → Motor control → Control stations → PLC/PCS [DP] → Stop
Device parameters → Motor control → Control stations → PLC/PCS [DP] → Open
Further function blocks → Standard functions → Test / Reset → Test1 - Input
Further function blocks → Standard functions → Emergency start → Emergency start - Input
Device parameters → Motor control → Control stations → Mode selector S1
Further function blocks → Standard functions → Test / Reset → Reset 1 - Input
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Status - ON < (CLOSED)
Status - OFF (Stop)
Status - ON > (OPEN)
Event - Prewarning overload (I>115 %)
Status - Interlocking time active
Status - Remote mode
Status - General fault
Status - general warning
Status - positioner runs in OPEN direction
Not connected
Status - positioner runs in CLOSED direction
Not connected
Not connected
Not connected
Not connected
Not connected
Maximum current I_max
Not connected
Not connected
Not connected
