Data Record 139 - Marking - Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
3.4.2.16

Data record 139 - Marking

For external faults, limit monitors, and monitoring functions of the temperature and analog
modules, user-specific texts can be configured for marking.
You can access the following texts via data record 139:
● External fault 1 to 6 (status information, warnings, and faults)
● Limit 1 to 4 (status information)
● TM1 warnings T> / trip T> (status information, warnings, and faults)
● AM1 warning/tripping 0/4 - 20 mA<> (status information, warnings and faults).
Can be parameterized to have various meanings, e.g. fill level >, bearing hot, etc. To simplify
diagnostics, these texts can be saved in the device. These can be created, read out and
displayed, for example, with SIMOCODE ES. The texts do not contain any functions.
Note
Changing the marking
Each change to the marking requires that the communication interface be restarted when the
web server is active. A new start interrupts all Ethernet and PROFINET links and
reestablishes them afterward.
Table 3- 67 Data record 139 - Marking
Byte.Bit Designation
0.0 Reserved
4.0 Reserved
10.0 Marking - External fault 1
20.0 Marking - External fault 2
30.0 Marking - External fault 3
40.0 Marking - External fault 4
50.0 Marking - External fault 5
60.0 Marking - External fault 6
70.0 Reserved
80.0 Reserved
90.0 Marking limit 1
100.0 Marking limit 2
110.0 Marking limit 3
120.0 Marking limit 4
130.0 Marking - TM warning T>
140.0 Marking - TM trip T>
150.0 Marking - Warning 0/4-20 mA>
160.0 Marking - Warning 0/4-20 mA<
170.0 Marking - Trip 0/4-20 mA>
180.0 Marking - Trip 0/4-20 mA<
190.0 Reserved
272
Type
Byte[4]
Byte[6]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
Byte[10]
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Information
