3.4 Tables, PROFINET data records
3.4.2.18

Data record 165 - Identification

You can access the following identifiers stored in the device:
● Plant identifier
● Location designation
● Installation date
● Comment.
Table 3- 69 Data record 165 - Identification
Byte.Bit Designation
0.0 Reserved
4.0 Plant identifier
36.0 Location designation
58.0 Date
74.0 Reserved
112.0 Comment
3.4.2.19

Data record 224 - Password protection

Description
● Password protection ON
If the data record is received with this control flag, the password protection is activated
and the password applied. If "Password protection on" and the password are not identical
at the time of receipt, the event "Event - Wrong password" is set and no change will be
made.
● Password protection OFF
If the data record is received with this control flag, the password protection is deactivated.
If the password is incorrect, the event "Event - Wrong password" is set and no change is
made.
Table 3- 70 Data record 224 - Password protection
Byte.Bit Designation
0.0 Reserved
4.0 Control flag:
0 = Password protection off, 1 = Password protection on
4.1 Reserved
8.0 Password
16.0 Reserved
274
Type
Byte[4]
Byte[32]
Byte[22]
Byte[16]
Byte[38]
Byte[54]
Type
Byte[4]
Bit
Bit[31]
Byte[8]
Byte[8]
