Tables, data records
3.6 EtherNet/IP data tables
3.6.6

Device Diagnosis object

The Device Diagnosis object supplies information about the current status of the device. This
object contains details of all fault messages, warnings and events that relate to the relevant
SIMOCODE device.
● Class code: 0x0096
● Class attributes: 0
● Number of instances: 1
● Object length: 46 bytes
Table 3- 93 General services for the Device Diagnosis object
Service code Available service
Class
0x01 No
0x0E No
Table 3- 94 Attributes of instance 1 for the Diagnosis object
Attribute ID Access
1 Get
Details of the meaning of individual diagnostic bits can be found in Chapter Data record 92 -
Device diagnostics (Page 229).
Note
Functional Example of EtherNet/IP
A functional example of EtherNet/IP in the Industry Online Support provides this information
as a preprogrammed, user-defined data type for the Rockwell Studio 5000 environment.
328
Service designation
Instance
Yes Get_Attributes_All
Yes Get_Attribute_Single
Designation
Diagnostic bits
Description
Supplies contents of all attributes
Supplies contents of one attribute
Data type
Byte[46]
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
