Data Record 131 - Basic Device Parameters 2 (Plug Binary) - Siemens SIMOCODE pro Function Manual

3.3.2.12

Data record 131 - Basic device parameters 2 (plug binary)

Table 3- 34 Data record 131 - Basic device parameters 2
Byte.Bit Designation (PRM group)
0.0 Reserved
4.0 Byte parameters (40)
4.0 BU - Output 1
5.0 BU - Output 2
6.0 BU - Output 3
7.0 Reserved
8.0 OP - LED green 1
9.0 OP - LED green 2
10.0 OP - LED green 3
11.0 OP - LED green 4
12.0 OP - LED yellow 1
13.0 OP - LED yellow 2
14.0 OP - LED yellow 3
15.0 Reserved
16.0 Cyclic send - Bit 0.0
17.0 Cyclic send - Bit 0.1
18.0 Cyclic send - Bit 0.2
19.0 Cyclic send - Bit 0.3
20.0 Cyclic send - Bit 0.4
21.0 Cyclic send - Bit 0.5
22.0 Cyclic send - Bit 0.6
23.0 Cyclic send - Bit 0.7
24.0 Cyclic send - Bit 1.0
25.0 Cyclic send - Bit 1.1
26.0 Cyclic send - Bit 1.2
27.0 Cyclic send - Bit 1.3
28.0 Cyclic send - Bit 1.4
29.0 Cyclic send - Bit 1.5
30.0 Cyclic send - Bit 1.6
31.0 Cyclic send - Bit 1.7
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Type Range
Byte[4]
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Byte 0 - 255
Tables, data records
3.3 Tables, PROFIBUS data records
Default Note
0
0
0
0
0
0
0
0
0
0
0
0
105 Default: Status
- ON<
106 Default: Status
- Off
107 Default: Status
- ON>
128 Default: Event
- Overload
operation
110 Default: Status
- Interlocking
time active
120 Default: Status
- Auto mode
96 Default: Status
- General fault
97 Default: Status
- group
warning
0
0
0
0
0
0
0
0
Information
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU1 BU2(+)
OP OPD
OP OPD
OP OPD
OP OPD
OP
OP
OP
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
181
