3.3.2.20

Data record 202 - Acyclic receive

Description
The acyclic receive data can be used for any functions. The receive data is available as
device-internal outputs (sockets).
Table 3- 42 Data record 202 - Acyclic receive
Byte.Bit Designation
0.0 Reserved
4.0 Acyclic receive - Bit 0.0
4.1 Acyclic receive - Bit 0.1
4.2 Acyclic receive - Bit 0.2
4.3 Acyclic receive - Bit 0.3
4.4 Acyclic receive - Bit 0.4
4.5 Acyclic receive - Bit 0.5
4.6 Acyclic receive - Bit 0.6
4.7 Acyclic receive - Bit 0.7
5.0 Acyclic receive - Bit 1.0
5.1 Acyclic receive - Bit 1.1
5.2 Acyclic receive - Bit 1.2
5.3 Acyclic receive - Bit 1.3
5.4 Acyclic receive - Bit 1.4
5.5 Acyclic receive - Bit 1.5
5.6 Acyclic receive - Bit 1.6
5.7 Acyclic receive - Bit 1.7
6.0 Acyclic receive - Analog value
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Tables, data records
3.3 Tables, PROFIBUS data records
Type Information
Byte[4]
BU0 BU1 BU2(+)
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Word
