Siemens SIMOCODE pro Function Manual page 75

ChannelErrorType Meaning
0x102C
0x102D
0x102E
0x102F
0x1040
0x1041
0x1042
0x1043
0x1045
0x1047
0x1048
0x1049
0x104A
0x104B
0x104C
0x1055
0x1057
0x105B
0x105C
0x105D
0x1061
0x1062
0x1070
0x1071
0x1072
0x1073
0x1074
0x1075
1) Further details of the cause of error can be obtained by reading data record 92
"Device diagnostics."
Data block "User Structure Identifier (USI)"
Table 2- 26
USI
0x0000 - 0x7FFF
0x8000
0x8002
0x9000 - 0x9FFF
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
TM1 sensor error
TM1 out of range
TM2 trip level T>
TM2 sensor error
Trip level I>
Trip level I<
Trip level P>
Trip level P<
Trip level cos phi<
Trip level U<
AM1 trip level 0/4-20mA>
AM1 trip level 0/4-20mA<
AM2 trip level 0/4-20mA>
AM2 trip level 0/4-20mA<
Stalled rotor
Test trip
Number of starts>
AM1 open circuit
AM2 open circuit
DM-F safety-related tripping
DM-F wiring
DM-F cross circuit
External fault 1
External fault 2
External fault 3
External fault 4
External fault 5
External fault 6
User Structure Identifier (USI)
Meaning
Manufacturer-specific diagnostics
Channel diagnostics
Extended channel diagnostics
Profile-specific
Communication
2.2 PROFINET communication
75
