Tables, data records
3.4 Tables, PROFINET data records
No. Designation
78
79
80 Contactor controls
81
82
83
84
85
86
87
88 Lamp controls
89
90
91
92
93
94
95
96 Status information - General
97
98
99
100
101
102
103
104 Status information - Receive
105
106
107
108
109
110
111
112
113
114
115
116
117
214
Designation
Reserved
Reserved
Contactor controls 1 QE1
Contactor controls 2 QE2
Contactor controls 3 QE3
Contactor controls 4 QE4
Contactor controls 5 QE5
Reserved
Reserved
Reserved
Display - QLE<<(ON<<)
Display - QLE<(ON<)
Indication - QLA (OFF)
Display - QLE>(ON>)
Display - QLE>>(ON>>)
Display - QLS (fault)
Reserved
Reserved
Status - General fault
Status - General warning
Status - Device
Status - Bus
Status - PLC/PCS
Status - Current flowing
Status – PE command Start_Pause pending
Reserved
Status - ON<<
Status - ON<
Status - Off
Status - ON>
Status - ON>>
Status - Start active
Status - Interlocking time active
Status - Change-over pause active
Status - Runs in open direction
Status - Runs in close direction
Status - FC
Status - FO
Status - TC
Status - TO
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Information
Dependent on the
control function
Dependent on the
control function
IM UM(+)
Dependent on the
control function
All reversing starters
and positioners
Star-delta starter,
Dahlander starter,
pole-changing starter
Dependent on the
control function
SIMOCODE pro - Communication
