Siemens SIMOCODE pro Function Manual page 284

Tables, data records
3.5 Modbus data tables
Input/holding Type
register
Address high/low
high Bit
0x1C05 low Bit
high Bit
0x1C06 low Bit
high Bit
284
Discrete Identifier
input / coil
address
0x1C48 Event - Stalled rotor
0x1C49 Reserved bit[1]
0x1C4A Reserved bit[1]
0x1C4B Event - No start permitted
0x1C4C Event - No. of starts >
0x1C4D Event - Just one start possible
0x1C4E Event - Motor operating hours >
0x1C4F Event - Motor stop time >
0x1C50 Event - Limit 1
0x1C51 Event - Limit 2
0x1C52 Event - Limit 3
0x1C53 Event - Limit 4
0x1C54 Event - External fault 1
0x1C55 Event - External fault 2
0x1C56 Event - External fault 3
0x1C57 Event - External fault 4
0x1C58 Event - External fault 5
0x1C59 Event - External fault 6
0x1C5A Reserved event - External fault 7
0x1C5B Reserved event - External fault 8
0x1C5C Event - AM1 open circuit
0x1C5D Event - DM-F safety-related tripping
0x1C5E Event - DM-F - Test requirement
0x1C5F Reserved
0x1C60 Event - timestamp function active + ok
0x1C61 Reserved
0x1C62 Event - DM-FL safety ok
0x1C63 Reserved
0x1C64 Event - Configured operator panel missing
0x1C65 Event - Module not supported
0x1C66 Event - module voltage missing
0x1C67 Reserved
0x1C68 Event - memory module read in
0x1C69 Event - memory module programmed
0x1C6A Event - Memory module erased
0x1C6B Reserved
0x1C6C Event - Initialization module read in
0x1C6D Event - Initialization module programmed
0x1C6E Event - Initialization module cleared
0x1C6F Event - Addressing plug read in
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Access
1)
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
