Siemens SIMOCODE pro Function Manual page 186

Tables, data records
3.3 Tables, PROFIBUS data records
Byte.Bit Designation (PRM group)
7.5 Monitoring external fault 6
7.6 Reserved
7.7 Reserved
8.0 Calculation module 2 - Operating
mode
8.1 Reserved
8.2 DM-F - Safe tripping function
8.3 DM-F - reset safety-related tripping
8.4 Time stamping active
8.5 Reserved
8.6 Reserved
8.7 Reserved
9.0 DM-FL - Configuration 1
9.1 DM-FL - Configuration 2
9.2 DM-FL - Configuration 3
9.3 DM-FL - Configuration 4
9.4 DM-FL - Configuration 5
9.5 DM-FL - Configuration 6
9.6 DM-FL - Configuration 7
9.7 DM-FL - Configuration 8
10.0 Bit[2] - Parameters (21)
10.0 3UF50 basic type
10.2 Reserved
10.4 UVO timebase
10.6 UVO operating mode
11.0 Trip monitoring U<
11.2 Warning monitoring U<
11.4 Reserved
11.6 Reserved
12.0 Trip monitoring 0/4-20 mA>
12.2 Warning monitoring 0/4-20 mA>
12.4 Trip monitoring 0/4-20 mA<
12.6 Warning monitoring 0/4-20 mA<
13.0 Monitoring limit 1
186
Type Range Unit
Bit 0, 1
Bit
Bit
Bit 0, 1
Bit
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit
Bit
Bit
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit 0, 1
Bit[2] 0, 1, 2
Bit[2]
Bit[2] 0, 1, 2
Bit[2] 0, 1
Bit[2] 0, 1, 2
Bit[2] 0, 1, 2
Bit[2]
Bit[2]
Bit[2] 0, 1, 2, 3
Bit[2] 0, 1, 2, 3
Bit[2] 0, 1, 2, 3
Bit[2] 0, 1, 2, 3
Bit[2] 0, 1, 2, 3
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Default Note
0 1 = Only motor
ON
0
0
0 0 = Word
1 = D-word
0
0 0 = No
1 = Yes
0 0 = Manual,
1 = Auto
0
0
0
0
0 Configurable
parameters
0
comparable with
0
the module
0
configuration
0
0
0
0
0
0
0 0 = 100 ms,
1 = 1 s,
2 = 10 s
0 0 = Deactivated,
1 = Activated
1 0 = ON (always)
1 = on+
1
(always, not TPF)
2 = RUN (motor
ON, not TPF)
0
0
0 0 = ON (always)
1 = ON +
0
(always, not TPF)
0
2 = RUN (motor
0
ON, not TPF)
0
SIMOCODE pro - Communication
Information
BU2(+)
BU2(+)
DM-F
DM-F
BU2(+)
DM-FL
DM-FL
DM-FL
DM-FL
DM-FL
DM-FL
DM-FL
DM-FL
BU2(+)
BU2(+)
BU2(+)
UM(+)
UM(+)
AM1
AM1
AM1
AM1
BU2(+)
