Data block "API"
API (Application Process Identifier): SIMOCODE pro uses the standard API 0.
Data blocks "SlotNumber," "SubslotNumber"
As a compact PROFINET IO Device, SIMOCODE pro V PN (GP) has the following structure:
Table 2- 18
Designation
Head module
- Interface
- Port 1
- Port 2
I/O module
PROFIsafe
1) Only in conjunction with fail-safe DM-F PROFIsafe expansion module
Data block "ChannelNumber"
Table 2- 19
ChannelNumber
0x0000 - 0x7FFF
0x8000
Data block "ChannelProperties"
Table 2- 20
15
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Data blocks "SlotNumber," "SubslotNumber"
1)
ChannelNumber
ChannelProperties
14 13 12 11
.Specifier
.Direction
SlotNumber
0x0000
0x0001
0x0002
Meaning
Manufacturer-specific
Submodule
10 9 8 7
.Acc.
.Qualifier
2.2 PROFINET communication
SubslotNumber
0x0001
0x8000
0x8001
0x8002
0x0001
0x0001
6 5 4 3
.Type
Communication
2 1 0
