3.3.2.2

Data record 0/1 - S7 system diagnostics

Table 3- 24 Data record 0/1 S7 system diagnostics
Byte.Bit DR0 DS1
0.0 X X
0.1 X X
0.2 X X
0.3 X X
0.4 X X
0.5 X X
0.6 X X
0.7 X X
1.0 X X
1.4 X X
1.5 X X
1.6 X X
1.7 X X
2.0 X X
2.1 X X
2.2 X X
2.3 X X
2.4 X X
2.5 X X
2.6 X X
2.7 X X
3.0 X X
3.1 X X
3.2 X X
3.3 X X
3.4 X X
3.5 X X
3.6 X X
3.7 X X
4.0 X
5.0 X
6.0 X
7.0 X
8.0 X
8.1 X
8.2 X
8.3 X
8.4 X
8.5 X
160
Designation
Module fault / OK
Internal fault
External fault
Channel fault
External auxiliary voltage missing
Front panel plug missing
Module not parameterized
Wrong parameters on module
Module type
Channel information available
Application information available
Substitute diagnosis alarm
Reserved = 0
Application module wrong / missing
Communication fault
Operating state (0=RUN, 1=STOP)
Time monitoring activated
Supply voltage within module failed
Battery flat (BATTF)
Total backup power failed
Reserved = 0
Rack failure (detected by IM / UM)
Processor failure
EEPROM error
RAM error
ADU/DAU error
Blown fuse
PRAL missing
Reserved = 0
Channel type
Length of the channel-specific diagnostics
Number of channels
Channel fault vector (one bit per channel)
Reserved
Short circuit
Undervoltage
Overvoltage
Overload
Overtemperature
Type No error Error
Bit 0 1
Bit 0 0
Bit 0 1
Bit 0 1
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit[4] 3 3
Bit 1 1
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Byte 0x7D 0x7D
Byte 0x20 0x20
Byte 0x01 0x01
Byte 0x00 0x01
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
Bit 0 0
