3.4 Tables, PROFINET data records
3.4.2.13

Data record 133 - Extended device parameters 2 (plug binary)

Table 3- 64 Data record 133 - Extended device parameters
Byte.Bit Designation (PRM group)
0.0 Reserved
4.0 Byte parameters (41)
4.0 DM1 - Output 1
5.0 DM1 - Output 2
6.0 DM2 - Output 1
7.0 DM2 - Output 2
8.0 Reserved
9.0 Reserved
10.0 Reserved
11.0 Reserved
12.0 Reserved
13.0 Reserved
14.0 Reserved
15.0 Reserved
16.0 Reserved
17.0 Reserved
18.0 Reserved
19.0 Reserved
20.0 Analog value recording - Trigger input
21.0 Reserved
22.0 Control station - Local control [LC] ON<<
23.0 Control station - Local control [LC] ON>>
24.0 Control station - PLC/PCS [PN] ON<<
25.0 Control station - PLC/PCS [PN] ON>>
26.0 Control station - PC/OPC UA[OCM] ON<<
27.0 Control station - PC/OPC UA[OCM] ON<<
28.0 Control station - Operator panels [OP] ON>>
29.0 Control station - Operator panels
[OP]<>/<<>>
30.0 Control function - ON<<
31.0 Control function - ON>>
32.0 Auxiliary control input - FC
33.0 Auxiliary control input - FO
34.0 Auxiliary control input - TC
35.0 Auxiliary control input - TO
36.0 External fault 5 - Input
37.0 External fault 6 - Input
38.0 Reserved
39.0 Reserved
260
Type Range Default
Byte[4]
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0
Byte 0
Byte 0
Byte 0
Byte 0 - 255 0
Byte 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0 - 255 0
Byte 0
Byte 0
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Note Information
DM1 DM-F
DM1 FM-F
DM2
DM2
Dependent
on the
control
function
SIMOCODE pro - Communication
