3.6 EtherNet/IP data tables
3.6.3

Message Router object

The Message Router object is defined by CIP. It does not possess any class or instance
attributes, but simply transfers explicit messages to the relevant objects.
3.6.4

Assembly object

The following information applies to the Assembly object of the SIMOCODE pro V
EtherNet/IP device:
● Class code: 0x04
● Class attributes: 1, 2, 3
● Number of instances: 13.
Instance 2: Output assembly basic overload from ODVA Profile
The tables below describe in each case the format of attribute 3 of the relevant assembly
instance.
Byte Bit 7
0 Reserved
Instance 50: Input assembly basic overload from ODVA Profile
The table below describes the format of attribute 3:
Byte Bit 7
0 Reserved
Instance 51: Input assembly extended overload from ODVA Profile
The table below describes the format of attribute 3:
Byte Bit 7
0 Reserved
316
Bit 6 Bit 5
Reserved Reserved
Bit 6 Bit 5
Reserved Reserved
Bit 6 Bit 5
Reserved Reserved
Bit 4 Bit 3
Reserved Reserved
Bit 4 Bit 3
Reserved Reserved
Bit 4 Bit 3
Reserved Reserved
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Bit 2 Bit 1
Fault Reset Reserved
Bit 2 Bit 1
Reserved Reserved
Bit 2 Bit 1 Bit 0
Reserved Warning Faulted / Trip
SIMOCODE pro - Communication
Bit 0
Reserved
Bit 0
Faulted / Trip
