Byte.Bit Designation (PRM group)
25.0
External fault 3 - Reset also
by
25.4
External fault 4 - Reset also
by
26.0
Limit monitor - Hysteresis
for limit monitor
26.4
EM+
- hysteresis
2)
27.0
Reserved
27.4
Reserved
28.0
Byte parameters (28)
28.0
Internal ground fault - Delay Byte
29.0
Overload protection - Class
30.0
Motor protection - Delay
with overload operation
31.0
Motor protection -
Unbalance protection level
32.0
Unbalance protection -
Delay with unbalance
33.0
Interlocking time
34.0
FB time
35.0
Trip level I>
36.0
Warning level I>
37.0
Trip level I<
38.0
Warning level I<
39.0
Stalled rotor level
40.0
Trip delay I>
41.0
Warning delay I>
42.0
Trip delay I<
43.0
Warning delay I<
44.0
Blocking delay
45.0
Monitoring the number of
starts - Permissible starts
46.0
Reserved
47.0
EM / MM
- delay warning
2)
48.0
Truth table 1 type 3I/1O
49.0
Truth table 2 type 3I/1O
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Type Range
Unit
Bit[4] 0 -
1111B
Bit[4] 0 -
1111B
Bit[4] 0 - 15
1 %
Bit[4]
0 - 15
1 %
Bit[4]
Bit[4]
0 - 255
100 ms 5
Byte
5, 7
,
3)
10 ... 35,
40
Byte
0 - 255
100 ms 5
Byte
0 - 100
1 %
Byte
0 - 255
100 ms 5
Byte
0 - 255
1 s
Byte
0 - 255
100 ms 5
Byte
0 - 255
4 % / I
s
Byte
0 - 255
4 % / Is 0
Byte
0 - 255
4 % / Is 0
Byte
0 - 255
4 % / Is 0
Byte
0 - 255
4 % / Is 0
Byte
0 - 255
100 ms 5
Byte
0 - 255
100 ms 5
Byte
0 - 255
100 ms 5
Byte
0 - 255
100 ms 5
Byte
0 - 255
100 ms 5
Byte
1 - 255
Byte
Byte
0 - 255
100 ms 1
Byte
0 -
1111111
1B
Byte
0 -
1111111
1B
3.3 Tables, PROFIBUS data records
Default
Note
0101B
Bit[4] = OFF command
reset
0101B
5
5
0
0
10
40
0
0 = disabled
0
1
0
0
0
Tables, data records
Information
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU2(+)
BU0 BU2(+)
BU0 BU1 BU2(+)
BU2+
IM / UM
BU0 BU1 BU2(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
IM / UM(+)
BU0 BU1 BU2(+)
BU0 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
179
