3.3 Tables, PROFIBUS data records
3.3.2.3

Data record 63 - Analog value recording

Table 3- 25 Data record 63 - Analog value recording
Byte.Bit Designation
0.0 StartPos
2.0 Channel No.
3.0 Analog value record currently running Bit
3.1 Trigger event occurred
3.2 Reserved
4.0 Measured value (0)
6.0 Measured value (1)
...
122.0 Measured value (59)
124.0 Reserved
The unit of the measured value is dependent on the assigned analog value. You will find all
available analog values with their units in Chapter Socket assignment table - analog
(Page 150).
3.3.2.4

Data record 67 - Process image output

Table 3- 26 Data record 67 - Process image output
Byte.Bit Designation
0.0 Cyclic receive - Bit 0.0
0.1 Cyclic receive - Bit 0.1
0.2 Cyclic receive - Bit 0.2
0.3 Cyclic receive - Bit 0.3
0.4 Cyclic receive - Bit 0.4
0.5 Cyclic receive - Bit 0.5
0.6 Cyclic receive - Bit 0.6
0.7 Cyclic receive - Bit 0.7
1.0 Cyclic receive - Bit 1.0
1.1 Cyclic receive - Bit 1.1
1.2 Cyclic receive - Bit 1.2
1.3 Cyclic receive - Bit 1.3
1.4 Cyclic receive - Bit 1.4
1.5 Cyclic receive - Bit 1.5
1.6 Cyclic receive - Bit 1.6
1.7 Cyclic receive - Bit 1.7
2.0 to 3.7 Cyclic receive - Analog value
162
Type Range
Word 0
Byte 1
0, 1
Bit 0, 1
Bit[6] 0
Word 0 ... 65535
Word 0 ... 65535
Word 0 ... 65535
Byte[76] 0
Default (also see parameters)
Control station - PLC/ PCS [DP] ON<
Control station - PLC/PCS [DP] OFF
Control station - PLC/PCS [DP] ON>
Test 1
Motor protection - Emergency start
Mode selector S1
Reset 1
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Information
BU2(+)
BU2(+)
BU2(+)
BU2(+)
BU2(+)
BU2(+)
BU2(+)
Type Information
Bit BU0 BU1 BU2(+)
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Word BU0 BU2(+)
SIMOCODE pro - Communication
