8 Using the Control Panel

8.1 Navigating on the Control Panel

Context:
The data of the AC drive is in menus and submenus. Follow these instructions to navigate in the menu structure on the control panel.
Procedure
1. To move between the menus, use the Browser buttons Up and Down on the keypad.
2. To go into a group or an item, push the Menu button Right.
To go back to the previous level, push the Menu button Left.
The display shows the current location in the menu, for example S6.3.2. The display also shows the name of the group or
item in the current location.
RUN
A
B
Monitor
C
A The location on the menu
C The number of items that are available or the item
value.
Illustration 40:

8.2 Using the Monitoring Menu (M1)

Context:
Follow these instructions to monitor the actual values of the parameters and signals.
The values cannot be changed in the Monitoring menu. To change the values of parameters, see
the Values Digit by Digit.
Danfoss A/S © 2018.06
Navigation Items on the Control Panel
READY
Keypad
V1 V1
B The description (name of the page)
Using the Control Panel
8.3.2 Selecting Values or 8.3.3 Editing
DPD00910G | 85
