Operating guide | VACON® NXS/NXP Air-cooled
Code Function
S6.8.3.4 System load
S6.8.4 Applications
S6.8.4.# Name of application
D6.8.4.#. 1 Application ID
D6.8.4.#. 2 Applications: Version
D6.8.4.#. 3 Applications: Firmware inter-
face
S6.8.5 Hardware
I6.8.5.1 Info: Power unit type code
I6.8.5.2 Info: Unit voltage
I6.8.5.3 Info: Brake chopper
I6.8.5.4 Info: Brake resistor
S6.8.6 Expander boards
S6.8.7 Debug menu

8.7.3 Changing the Language

Context:
Use these instructions to change the language of the control panel. The possible languages are different in all language packages.
Procedure
1. In the System menu (M6), find the Language selection page (S6.1) with the Browser buttons.
2. To go to the edit mode, push the Menu button Right.
The name of the language starts to blink.
3. To select the language for the control panel texts, use the Menu buttons Up and Down.
4. To accept the selection, push the [enter] button.
The name of the languages stops to blink and all text information on the control panel shows in the selected language.

8.7.4 Changing the Application

Context:
The application can be changed in the Application selection page (S6.2). When the application is changed, all parameters are reset.
For more information on the Application Package, see VACON
100 | Danfoss A/S © 2018.06
Min Max Unit
V
®
NX All in One Application Manual.
Using the Control Panel
Default Cust Description
For Application program-
ming only. Speak to the fac-
tory to get instructions.
DPD00910G
