Operating guide | VACON® NXS/NXP Air-cooled
Index Monitored value
V1.1 Output frequency
V1.2 Frequency reference
V1.3 Motor speed
V1.4 Motor current
V1.5 Motor torque
V1.6 Motor power
V1.7 Motor voltage
V1.8 DC link voltage
V1.9 Unit temperature
V1.10 Motor temperature
V1.11 Analog input 1
V1.12 Analog input 2
V1.13 DIN 1, 2, 3
V1.14 DIN 4, 5, 6
V1.15 DO1, RO1, RO2
V1.16 Analog I
out
V1.17 Multimonitoring items
1
If the AC drive only has +24 V supply (for control board power-up), this value is not reliable.
®
See VACON All in One Application Manual for more monitored values.

8.3 Using the Parameter Menu (M2)

8.3.1 Finding the Parameter

Context:
Use these instructions to find the parameter to edit.
Danfoss A/S © 2018.06
Unit ID Description
Hz 1 The output frequency to the motor
Hz 25 The frequency reference to motor control
rpm 2 The actual speed of the motor in rpm
A 3 Measured motor current
% 4 The calculated shaft torque
% 5 The calculated motor shaft power in percentage
V 6 The output voltage to the motor
V 7 The measured voltage in the DC-link of the drive
°C 8 The heat sink temperature in Celsius or Fahrenheit
% 9 The calculated motor temperature in percentage of the nominal temperature. See
®
VACON All in One Application Manual.
V/mA 13 AI1
(1)
V/mA 14 AI2
(1)
15 Shows the status of the digital inputs 1-3
16 Shows the status of the digital inputs 4-6
17 Shows the status of the digital and relay outputs 1-3
mA 26 AO1
Shows 3 monitored values to select from. See
of Multimonitoring
8.7.6.9 Enabling/Disabling the Change
Items.
Using the Control Panel
DPD00910G | 87
