Danfoss Vacon NXP Series Operating Manual page 34

Operating guide | VACON® NXS/NXP Air-cooled
A
A
2
A The clearance around the drive (see also B and C)
C The free space above the drive
Illustration 10: Installation Space
Table 6: Minimum Clearances around the AC Drive in mm (in inch)
Drive type
0003 2-0012 2
0003 5-0012 5
0017 2-0031 2
0016 5-0031 5
0048 2-0061 2
0038 5-0061 5
0004 6-0034 6
34 | Danfoss A/S © 2018.06
B
A
A
2
A
20
(0.79)
20
(0.79)
30
(1.18)
B
B The distance from a drive to a second drive, or the distance to
the cabinet wall
D The free space below the drive
B C
20 100
(0.79) (3.94)
20 120
(0.79) (4.72)
20 160
(0.79) (6.30)
Mounting the Unit
D
50
(1.97)
60
(2.36)
80
(3.15)
DPD00910G
