Operating guide | VACON® NXS/NXP Air-cooled
Table 2: Description of the Type Code
Code Description
VACON This part is same for all the products.
NXP The product range:
• NXP = VACON
• NXS = VACON
0003 The drive rating in amperes. For example, 0003 = 3 A
5 The mains voltage:
• 2 = 208–240 V
• 5 = 380–500 V
• 6 = 525–600 V (IEC)
525–600 V (cULus)
A The control panel:
• A = standard (text display)
• B = no local control panel
• F = dummy keypad
• G = graphic display
2 The protection rating:
• 0 = IP00
• 2 = IP21 (UL Type 1)
• 5 = IP54 (UL Type 12)
• T = flange-mounted (through-hole mounted)
H The EMC emission level:
• C = complies with the category C1 of standard IEC/EN 61800-3 + A1, 1st environment, and nominal voltage less
than 1000 V
• H = complies with the category C2 of standard IEC/EN 61800-3 + A1, fixed installations, and nominal voltage
less than 1000 V
• L = complies with the category C3 of standard IEC/EN 61800-3 + A1, 2nd environment, and nominal voltage less
than 1000 V
• T = complies with the standard IEC/EN 61800-3 + A1 when used in IT networks (C4).
• N = No EMC emission protection. An external EMC filter is necessary.
1
The brake chopper:
• 0 = No brake chopper
• 1 = Internal brake chopper
• 2 = Internal brake chopper and resistor, available for:
- 208–240 V (FR4-FR6)
- 380–500 V (FR4-FR6)
Danfoss A/S © 2018.06
®
NXP
®
NXS
(1)
Product Overview
DPD00910G | 17
