Operating guide | VACON® NXS/NXP Air-cooled
Procedure
1. To find the Keypad control menu, scroll down in the main menu until the location indication M3 shows on the first line of the
display.
STOP
Keypad control
2. To go to the Keypad control menu from the main menu, push the Menu button Right.

8.4.2 Keypad Control Parameters M3

Table 13: Keypad Control Parameters, M3
Index Parameter
P3.1 Control place
R3.2 Keypad reference
P3.3 Direction (on keypad)
P3.4 Stop button

8.4.3 Changing the Control Mode

Context:
3 control modes are available to control the AC drive. For each control place, a different symbol shows on the display:
The control mode
I/O terminals
Keypad (control panel)
Fieldbus
Danfoss A/S © 2018.06
READY
I/O term
P1
P4
Min Max
1 3
P2.1.1 P2.1.2
0 1
0 1
Unit Default Cust
1
Hz 0.00
0
1
Using the Control Panel
ID Description
125 The control mode
1 = I/0 terminal
2 = Keypad (control panel)
3 = Fieldbus
123 0 = Forward
1 = Reverse
114 0 = Limited function of Stop button
1 = Stop button always enabled
The symbol
I/O term
Keypad
Bus/Comm
DPD00910G | 91
