Operating guide | VACON® NXS/NXP Air-cooled
Enclo- Drive type
sure size
FR5 0017 2
0016 5
0025 2
0022 5
0031 2
0031 5
FR6 0038 5
0048 2
0045 5
0061 2
0061 5
FR7 0075 2
0072 5
0088 2
0087 5
0114 2
0105 5
FR8 0140 2
0140 5
0170 2
0168 5
0205 2
0205 5
FR9 0261 2
0261 5
0300 2
0300 5
1
Uses a correction factor 0.7
Danfoss A/S © 2018.06
Fuse Class Mains, Motor, and brake re-
Fast Act-
sistor cable Cu [AWG]
ing (T/J)
[A]
20 3*12 AWG + 12 AWG
30 3*10 AWG + 10 AWG
40 3*8 AWG + 8 AWG
50 3*8 AWG + 8 AWG
60 3*8 AWG + 8 AWG
90 3*6 AWG + 6 AWG
90 3*4 AWG + 6 AWG
110 3*2 AWG + 6 AWG
150 3*2 AWG + 4 AWG
175 3*2/0 AWG + 2 AWG
250 3*3/0 AWG + 1/0 AWG
250 3*300 kcmil + 2/0 AWG
350 3*350 kcmil + 3/0 AWG
2*(3*250 kcmil + 2/0 AWG)
400 2*(3*250 kcmil + 2/0 AWG)
Mains terminal [AWG]
(1) (2)
18 AWG - 8 AWG
18 AWG - 8 AWG
18 AWG - 8 AWG
14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
14 AWG - 1 AWG Cu
10 AWG - 1 AWG Al
4 AWG - 3/0 AWG Cu/Al
3/0 AWG - 350 kcmil Cu/Al
3/0 AWG - 350 kcmil Cu/Al
3/0 AWG - 350 kcmil Cu/Al
3/0 AWG - 350 kcmil Cu/Al
Specifications
Grounding terminal
[AWG]
18 AWG - 8 AWG
18 AWG - 8 AWG
18 AWG - 8 AWG
14 AWG - 2 AWG
14 AWG - 2 AWG
14 AWG - 2 AWG
10 AWG - 2/0 AWG
10 AWG - 2/0 AWG
10 AWG - 2/0 AWG
10 AWG - 3/0 AWG
10 AWG - 3/0 AWG
10 AWG - 3/0 AWG
10 AWG - 3/0 AWG
10 AWG - 3/0 AWG
DPD00910G | 139
