Operating guide | VACON® NXS/NXP Air-cooled
A
C
FR8
A Control terminals
C Grounding terminals
Illustration 19: FR8 Terminals

6.4.6 Get Access and Locate the Terminals for FR9

Context:
Follow these instructions to open the AC drive for installing the cables, for example.
54 | Danfoss A/S © 2018.06
B
B Motor terminals
Electrical Installation
DPD00910G
