Operating guide | VACON® NXS/NXP Air-cooled
Technical item or function
Control connections
(apply to boards OP-
TA1, OPTA2, and OP-
TA3)
Protections
1
For the motor thermal memory and the memory retention function to obey the UL 508C requirements, use the system software version NXS00001V175, NXS00002V177 or
NXP00002V186 or a newer version. If an older system software is used, install a motor overtemperature protection to comply with the UL regulations.
158 | Danfoss A/S © 2018.06
Analog input voltage
Analog input current
Digital inputs (6)
Auxiliary voltage
Output reference voltage
Analog output
Digital outputs
Relay outputs
Overvoltage trip limit
Undervoltage trip limit
Ground fault protection
Mains supervision
Motor phase supervision
Overcurrent protection
Unit overtemperature pro-
tection
Motor overload protection
Motor stall protection
Motor underload protection
Short-circuit protection of
+24 V and +10 V reference
voltages
Technical data
0...+10 V, Ri = 200 kΩ, (–10 V...+10 V joystick control)
Resolution 0.1% (NXP: 12-bit, NXS: 10-bit), accuracy ±1%
0(4)-20 mA, Ri = 250 Ω differential
Positive or negative logic; 18–30 VDC
+24 V, ±10%, max volt. ripple < 100 mVrms; max. 250 mA
Dimensioning: max. 1000 mA/control box (power back-up)
+10 V, +3%, max. load 10 mA
0(4)-20 mA; RL max. 500 Ω; Resolution 10 bit; Accuracy ±2%
Open collector output, 50 mA/48 V
2 programmable change-over relay outputs
Switching capacity (resistive): 24 VDC/8 A, 250 VAC/8 A, 125 VDC/0.4 A
Min.switching load: 5 V/10 mA
The 240 volt drives: 437 V DC
The 500 volt drives: 911 V DC
The 690 volt drives: 1200 V DC
Mains voltage 240 V: 183 V DC
Mains voltage 500 V: 333 V DC
Mains voltage 690 V: 461 V DC
If there is an ground fault in the motor or motor cable, only the AC drive
is protected.
Trips if some of the input phases are missing
Trips if some of the output phases are missing
Yes
Yes
Yes. (1)
The motor overload protection activates at 110% of the full load current.
Yes
Yes
Yes
Specifications
