Operating guide | VACON® NXS/NXP Air-cooled
A
FR6
A Control terminals
C Motor terminals
Illustration 17: FR6 Terminals

6.4.4 Get Access and Locate the Terminals for FR7

Context:
Follow these instructions to open the AC drive for installing the cables, for example.
50 | Danfoss A/S © 2018.06
B C
D
B Brake resistor terminals
Electrical Installation
DPD00910G
